PROSPACE+ Archive Shelf
Tubular shelving configured for archive and document storage. 7 shelf levels at 2,200 mm height with 350 mm depth optimised for standard archive boxes. Available in single-access (350 mm) or double-access (700 mm) depth. Clean aesthetic with no front-facing perforations, suitable for offices, hospitals and administrative environments.
- Load capacity up to 2,100 kg per pair of uprights
- Height up to 5,000 mm in one piece
- Adjustment pitch 40 mm
- Depth up to 1,000 mm
- Load up to 275 kg per shelf (evenly distributed)
- Clip-in assembly, no tools required
- Guaranteed European origin
Published capacities are configuration dependent. The final design, loads, dimensions, accessories and price must be confirmed for your installation.
Technical information
Use these catalogue details as a starting point for your discussion with our storage team.
Read the complete brochure| Product Range | PROSPACE+ |
|---|---|
| Shelf Type | Tubular (Archive Configuration) |
| Available Lengths | 940, 1210 mm |
| Available Depths | 350 mm (single-access), 700 mm (double-access) |
| Standard Height | 2,200 mm |
| Shelves Included | 7 per unit |
| Upright Finish | Epoxy paint RAL 7016 (anthracite grey) |
| Shelf Finish | Epoxy paint RAL 7035 or Sendzimir galvanised |
| Assembly | Clip-in system, no tools required |
| Adjustment Pitch | 40 mm |
| Aesthetic | No front-facing perforations on uprights |
| Origin | Made in France |
Accessories & Options
Applications
